DSE DSE4620 - Pressure Sensor List; Temperature Sensor List; Percentage Sensor List

Front Panel Configuration
79
7.3.12 PRESSURE SENSOR LIST
PRESSURE SENSOR LIST
Index Type
0 Not used
1 Dig Closed for Alarm
2 Dig Open for Alarm
3 VDO 5 Bar
4 VDO 10 Bar
5 Datcon 5 Bar
6 Datcon 10 Bar
7 Datcon 7 Bar
8 Murphy 7 Bar
9 CMB812
10 Veglia
11 User Defined
7.3.13 TEMPERATURE SENSOR LIST
TEMPERATURE SENOR LIST
Index Type
0 Not Used
1 Dig Closed for Alarm
2 Dig Open for Alarm
3 VDO 120 °C
4 Datcon High
5 Datcon Low
6 Murphy
7 Cummins
8 PT100
9 Veglia
10 Beru
11 User Defined
7.3.14 PERCENTAGE SENSOR LIST
PERCENTAGE SENSOR LIST
Index Type
0 Not Used
1 Dig Closed for Alarm
2 Dig Open for Alarm
3 VDO Ohm (10-180)
4 VDO Tube (90-0)
5 US Ohm (240-33)
6 GM Ohm (0-90)
7 GM Ohm (0-30)
8 Ford (73-10)
9 User Defined
