DSE DSE704 - Page 10

- 10 - 057-042 704 Operating Instructions Issue 2.1 18/06/2007 11:27:00 JR
FUNCTIONS AND CONFIGURATION TABLE
Function
! 1 ! 2
Value (Default in Bold)
Auxiliary Input 1
Function
O
{ { { {
{ { {
Immediate Warning
Close on Fault
{ {
O
Immediate Warning
Open on Fault
{
O
{
Immediate Shutdown
Close on Fault
{
O O
Immediate Shutdown
Open on Fault
O
{ {
Delayed Warning
Close on Fault
O
{
O
Delayed Warning
Open on Fault
O O
{
Delayed Shutdown
Close on Fault
O O O
Delayed Shutdown
Open on Fault
Programmable input, can be configured to on of the following
♦ Immediate warning close on fault – If the input is activated at any time the unit will alarm and energise the
common warning and common alarm output.
♦ Immediate warning open on fault – If the input is deactivated at any time the unit will alarm and energise the
common warning and common alarm output.
♦ Immediate shutdown close on fault – If the input is activated at any time the generator will be shutdown and
energise the common warning and common shutdown output. The generator can not be started.
♦ Immediate shutdown open on fault – If the input is deactivated at any time the generator will be shutdown and
energise the common warning and common shutdown output. The generator can not be started.
♦ Delayed warning close on fault – If the input is activated and the saftey time has elapsed the unit will alarm and
energise the common warning and common alarm output.
♦ Delayed warning open on fault – If the input is deactivated and the saftey time has elapsed the unit will alarm and
energise the common warning and common alarm output.
♦ Delayed shutdown close on fault – If the input is activated and the saftey time has elapsed the generator will be
shutdown and energise the common warning and common shutdown output.
♦ Delayed shutdown open on fault – If the input is deactivated and the saftey time has elapsed the generator will be
shutdown and energise the common warning and common shutdown output.
Auxiliary Input 2
Function
O
{ { {
O
{ { {
Immediate Warning
Close on Fault
{ {
O
Immediate Warning
Open on Fault
{
O
{
Immediate Shutdown
Close on Fault
{
O O
Immediate Shutdown
Open on Fault
O
{ {
Delayed Warning
Close on Fault
O
{
O
Delayed Warning
Open on Fault
O O
{
Delayed Shutdown
Close on Fault
O O O
Delayed Shutdown
Open on Fault
Programmable input, can be configured to on of the following
♦ Immediate warning close on fault – If the input is activated at any time the unit will alarm and energise the
common warning and common alarm output.
♦ Immediate warning open on fault – If the input is deactivated at any time the unit will alarm and energise the
common warning and common alarm output.
♦ Immediate shutdown close on fault – If the input is activated at any time the generator will be shutdown and
energise the common warning and common shutdown output. The generator can not be started.
♦ Immediate shutdown open on fault – If the input is deactivated at any time the generator will be shutdown and
energise the common warning and common shutdown output. The generator can not be started.
♦ Delayed warning close on fault – If the input is activated and the saftey time has elapsed the unit will alarm and
energise the common warning and common alarm output.
♦ Delayed warning open on fault – If the input is deactivated and the saftey time has elapsed the unit will alarm and
energise the common warning and common alarm output.
♦ Delayed shutdown close on fault – If the input is activated and the saftey time has elapsed the generator will be
shutdown and energise the common warning and common shutdown output.
♦ Delayed shutdown open on fault – If the input is deactivated and the saftey time has elapsed the generator will be
shutdown and energise the common warning and common shutdown output.
