057-042 704 Operating Instructions Issue 2.1 18/06/2007 11:27:00 JR - 13 -
5 SPECIFICATION
DC Supply: 8 Volts to 35 Volts DC Continuous.
Cranking Dropouts: Able to survive 0 Volts for 50 mS, providing supply was at
least 10 V before dropout and supply recovers to 5 Volts.
This is achieved without the need for internal batteries.
Max. Current: Operating 50mA
Standby 10mA
Alternator Input Range: 75 Volts (ph-N) to 277 Volts (ph-N) AC (+20%)
Mains Input Voltage 15 – 277 Volts (ph-N) AC (+20%)
Alternator Input Frequency: 50 - 60 Hz at rated engine speed
(Minimum: 75V AC Ph-N)
(Crank Disconnect from 15V Ph-N @ 20Hz)
Overspeed +14% (+24% overshoot)
Underspeed –20%
Mains Frequency 50 – 60 Hz
Start Output: 1.2 Amp DC at supply voltage.
Fuel Output: 1.2 Amp DC at supply voltage.
Auxiliary Outputs: 1.2 Amp DC at supply voltage.
Dimensions: 125mm x 165mm x 28 mm
Charge Fail: 12 Volts = 8 Volts CF 24 Volts = 16 Volts CF
Operating Temperature Range:
-30°C to + 70
0
C
Applicable Standards
Compliant with BS EN 60950 Low Voltage Directive
Compliant with BS EN 50081-2: 1992 EMC Directive
Compliant with BS EN 61000-6-4: 2000 EMC Directive
Compliance to European Legislation
Registered Component for USA & Canada
Deep Sea Electronics plc reserve the right to change specification without notice.
