5.4.3 GENERATOR
Contains electrical values of the generator (alternator), measured or derived from the module’s voltage and
current inputs.
• Generator Voltage (ph-N)
• Generator Voltage (ph-ph)
• Generator Frequency
• Generator Current
• Generator Earth Current
• Generator Load (kW)
• Generator Load (kVA)
• Generator Power Factor
• Generator Load (kVAr)
• Generator Load (kWh, kVAh, kVArh)
• Generator Phase Sequence
• Dual Mutual Status
Dual Mutual Status
Master Available
Slave Inhibited
Timer 00:59 Master
Available : The set is running and available
Inhibited : The set is prevented from running by the
‘other‘ controller
Master : The master set will call for the slave when the timer (hrs:mins)
expires.
Slave : The master will call for the slave until the timer (hrs:mins) expires.
