Installation
22
4.3 DSE2541 ENCLOSURE MOUNTED DISPLAY MODULE
NOTE: LCD display is fitted only to the following model numbers : 9460-01, 9460-02, 9461-
01, 9461-02
NOTE: Where factory fitted to the enclosure, the DSE2541-01 must not be removed.
Should an external, remote display be required, use DSE Part Number 2541-02 suitable for
remote location up to 1.2km from the host battery charger.
NOTE: These connections are made by the DSE factory and are included for information
only.
1 Plant Supply Negative 1mm² (AWG16)
2 Plant Supply Positive 1mm² (AWG16)
3 RS485 (Screen) N/A
Use only 120Ω RS485 approved
cable
4 RS485 (B) 0.5mm² (AWG20)
5 RS485 (A) 0.5mm² (AWG20)
NOTE: Screened 120Ω
ΩΩ
Ω impedance cable specified for use with RS485 must be used for the
RS485 link.
DSE stock and supply Belden cable 9841 which is a high quality 120Ω
ΩΩ
Ω impedance cable
suitable for RS485 use (DSE part number 016-030)
