DSE DSE9461 - Charge Graphic

Operation
32
6.2.7 CHARGE GRAPHIC
The LCD shows the charge graphic to show the selected charge curve. The currently active mode is
shown flashing in the module display.
6.2.7.1 THREE STAGE CHARGE PROFILE
Detail of charge curve display
NOTE: - A description of each charge mode is given earlier in this manual.
Flashing to show
charge mode
Boost (Bulk) charge
mode
Absorption charge
mode
Float charge mode
