DSIC DS5-AX - Device Specifications

DS5-AX User Manual Ver.0 2016. 03.17
10
Specifications
Characters
Descriptions
Display
4.3inch WVGA (480x800) IPS / Capacitive multi-touch
Dimensions (mm)
78(Grip: 58) x 225 x 58
Weight (g)
410g including battery
Battery
Li-ion 3.7V 5200mAh
Backup Battery
Li-ion 130mAh
Operating System
Android AOSP 4.4.2 KitKat
Processor
Exynos 5260 Hexa-Core (1.7GHz dual-core Cortex-A15 x 2, 1.3GHz quad-core Cortex-A7 x 4)
Memories(RAM/ROM)
LPDDR3 2GB/ 8GB
USB
USB2.0 On-The-Go (B-type)
External Interface
Micro USB, Micro SD slot, SIM slot (optional), SAM slot (optional)
Sound & Mic
Louder Speaker, Receiver, Mic
LED & Indication
Charging LED, Notification LED (Multi-color & Programmable), Vibration
Key buttons
34 Numeric Keys, Programmable F1~F10 keys)
54 Full Alpha Numeric Keys
Sensors
Ambient light sensor & Proximity sensor, 3-axis compass
Motion tracking sensors (3-axis gyroscope, 3-axis accelerometer, Digital motion processor)
Sealing & Drop
IP67, 1.8m multi-drop resistance to concrete
Storage Temperature
-20°C to 70°C
Operating Temperature
-20°C to 60°C
Humidity
95% non-condensing
Regulatory
KCC, CE, FCC, CCC, RoHS complaint
Optional Integration Features
WWAN
3.75G HSPA+/ 3G UMTS/ 2G GSM|GPRS|EDGE
4G LTE: T.B.D
WLAN
IEEE 802.11 a/b/g/n/ac
WLAN Security
WEP, WPA-PSK, WPA2-PSK, 802.1x EAP (PEAP-MSCHAPV2, PEAP-GTC, TLS, TTLS-PAP, TTLS-
MSCHAP, TTLS-MSCHAPV2, TTLS-GTC, PWD)
WPAN
Bluetooth v4.0 (Bluetooth
○
R
Smart Technology)
Scanner
SE4750 imager (1D & 2D)
Extraordinary scan range – Code39 barcode
- 20Mil: 4.5cm - 81.3cm
- 3mil: 7.9cm – 14.2cm
RFID (NFC) – T.B.D
13.56 MHz, ISO14443A&B, ISO15693, MIFARE, Felica, NFCIP-1, NFCIP-2
Camera
8.0M Pixel AF with Flash
GPS
Stand alone, A-GPS
Warranty
1 year manufacturer’s warranty
Default Accessories
· micro USB cable for charging & PC sync
· AC/DC Adapter & Country configured adaptor plug
· Screen protection film · Hand strap
Optional Accessories
· Desktop cradle: power, micro USB(OTG), RS232
· Gun Trigger
· Bumper · Quad Battery Charger
