DST RL-61 - Page 25

Component list RL-61
Description
Type, Drwg No etc
61
61L
Qty.
Art No
Notes
Rotor unit
Rotor DMR-550H10 (300 cpsi)   1 108256
Radial seal 0,35x35x1000mm; Teflon   1.5 105241
Periferal seal Felt+EPDM 1750x25   2 103131
Hose clamp Nemo-9 60-650   2 100275
Seal wet air box Tätningslist DST-2 15 mm   0,8 m 100217
Brusch seal Tätning borst -23mm   0,2 m 107922
Rotormotor
Robase 34.2-G250.F-X; 230V 50-60Hz; 0,5uF; 9W;
6rpm
 
1
112741
Beltpulley 24 5M 09 d=8

 1 100279
Beltpulley 15 5M 09 d=8 

1 102583
Belt
1870 5M 09
 
1
104654
Fans
Proc fan motor
0.75 kW 3x230/400V 50Hz
 
1
112733
Impeller
180x85 Ø19
 
1
112748
Reg fan motor
0.37 kW 3x230/400V 50Hz
 
1
115380
Impeller
160x62 Ø14
 
1
112747
Proc fan motor
1.5 kW 3x230V/400V 50Hz
 
1
112734
Impeller
200x50 Ø24
 
1
112746
Reg fan motor
0.55 kW 3x230/400V 50Hz
 
1
114664
Imepeller
180x62 Ø14
 
1
112745
Filter
Filter EP 600x240x50 F7
 
1 108897 Process
Filter EP 600x240x50 F7
 
1 108897 Regeneration
Regeneration heater -
Resistive heater
Reg.heater 9kW (4,5+4,5); 3x400V 

1 106292
Reg.heater 13,5 kW (9+4,5); 3x400V

 1 100910
Other
Electric box Dwg: 10680-03 

1 108937
Electric box Dwg: 11000-03

 1 110272
RL-61
