DST RL-61 - 11 Technical Data

24 RL-61, 61L EN.033 24.01Seibu Giken DST
EN
11 TECHNICAL DATA
1
Valid for inlet conditions 20 °C/ 60%RH (equal 1.2 kg/m3).
2
If no data is stated here the volume ow above is given at free blowing airow.
3
Unit connected to uninsulated ducts. Nominal airows.
4
Applies for dehumidiers with installed optional feature.
5
The current provided by the humidistat connection. Only use humidistats that are
capable of this load current.
6
(EN779 = ISO16890) G4 = Coarse 60%, M5 = ePM10 60%, F7 = ePM1 60%,
F9 = ePM1 85%
The content of in this document may be subject to change without prior notice. For
questions and comments regarding the content in this document, please send it to
Seibu Giken DST AB, ATT: Documentation, Avestagatan 33, 163 53 SPÅNGA,
SWEDEN.
E-mail: info@dst-sg.com, subject: Documentation.
RL-61 RL-61L
Capacity
Capacity [kg/h]
1
7.5 11
Nominal dry air ow [m3/h]
2
1300 1800
External static pressure dry air [Pa]
2
200 200
Nominal wet air ow [m3/h]
2
280 420
External static pressure wet air [Pa]
2
300 300
Regeneration heater - Electric
Heater power [kW] 9 13.5
Number of electric heater steps 2 2
Heating power in steps [kW]
1/2 - 4,5
2/2 - 9
1/2 - 9
2/2 - 13.5
Heating power with linear control [kW]
4
0-9 0-13.5
Humidistat 2 opens and reduce the power to [kW] 4.5 9
Total power - Electrical
Total motor power [kW] 1.12 2.05
Total power [kW] 10.12 15.55
Other electrical information
Supply fuse 3x400V/50Hz [A] 25 25
Humidistat connection 230VAC 230VAC
Humidistat supply current [A]
5
< 1 < 1
Temperature setpoint settings
Overheat protection TH1 [°C] 190 190
Thermostat TH2 [°C] 160 160
Overheat protection TH3 [°C] 80 80
Temperature limits
Max. process air inlet temperature [°C] 40 40
Max. operating temperature [°C] 50 50
Min. operating temperature [°C] -20 -20
Other technical data
Air lter class (regeneration/process) F7/F7 F7/F7
Filter change at pressure (G4/F7) [Pa]
6
200/250 200/250
Airow guard - Regeneration [Pa] 90 90
Delta P - Process/Regeneration [Pa] 30 30
Noise level [dB(A)]
3
- -
Regeneration air fan delay [min] 10 10
Weight [kg] 130 132
