5
Before You Start
•
Disconnect negative battery terminal. Consult a qualified technician for instructions.
•
Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it
would be subject to dust, dirt or excessive vibration.
Getting Started
• Insert the supplied keys into the slots as shown, and slide the unit out of the mounting sleeve.
•
Install mounting sleeve into opening, bending tabs to secure.
•
Connect wiring harness as shown on page 6. Consult a qualified technician if you are unsure.
•
Certain vehicles may require an installation kit and/or wiring harness adapter (sold separately).
• Reconnect negative battery terminal, and test for correct operation.
•
Snap trim ring into place (if required).
• Slide unit into mounting sleeve to secure.
XDCPA9BT INSTALLATION
Preparation
TRIM PLATE
UNIT
TAPTITE BINDING HEAD 5X6MM
TAPTITE TRUSS HEAD 5X6MM
