22
XDCPA9BT OPERATION
Rear RCA Aux Input
Rear Camera Operation - (Optional)
Connect an optional audio source into the RCA (rear) input.
Select auxiliary input from the Main Menu to listen to audio.
Adjust volume on the external audio source as needed (if connected to the
headphone output of the device).
Connect an optional rear camera to the Camera Input (Black RCA connector).
Refer to the wiring diagram for details.
Manual selection - Touch CAMERA icon from the Main Menu or from any
operational mode (when enabled) to select camera mode. Touch the top left area
on the screen to exit camera mode.
Note: The manual mode is for dedicated cameras that are ALWAYS on while
driving, it is not meant for cameras that are connected to the vehicle's reverse
light.
The unit will automatically select camera mode when connected to the reverse
lamp circuitry.
Note: The external video output is not active when using the rear camera input.
Auxiliary Input
Using Rear Camera
Auto Selection
