Dual XML8150 User Manual

6
XML8150 OPERATION
Power On/Off
Mode
Steering Wheel Interface
Input
Auxiliary Input
Volume
Mute
Reset
Display
Set the Clock
12/24-Hour Clock
Setup Menu
General Operation
Press oranyotherbuttontoturnuniton.Pressandhold
to turn unit off.
Press MODEtoselectbetweenAM/FM,auxiliaryinput,
operationofiPod,USB,SDandBluetoothmodes.Modesof
operationareindicatedinthedisplay.
Note:OperationofiPodmodewillnotappearunlessaniPod
devicehasbeenconnected.USBandSDmodeswillnot
appearunlessaUSBdevicehasbeenconnectedorSDcard
hasbeeninserted.
Note:iPodandiPhonedevicesmaybeconnectedtothefold-
outdockordirectlytotheUSBportontheXML8150.
Thesteeringwheelinterfaceinputlocatedonthebackofthe
headunitallowsconnectiontothePAC (Pacific Accessory
Corporation) SWI-PSinterfacemodule(soldseparately).Visit
www.pac-audio.comfordetails.
Toconfiguresteeringwheelcontrols,followtheinstructions
providedwiththePAC SWI-PSinterfacemodule.After
installingtheinterfacemodule,insertthemodule's3.5mm
jackintotheportonthebackoftheheadunit.
Insert3.5mmplugtoconnectyourportableaudiodevice.
Adjustvolumeusingvolumeknob(00-46).
Press tosilencetheaudio.“MUTE”willflashinthe
display.Press againtocancel.
PresstheRESETbutton,locatedonthefrontpanel,toreset
theunitbacktothefactorysettingsifabnormaloperation
occurs.
Press DISPtotogglebetweenitemssuchasclock,radio
frequency,orID3tagsonginformation.
Withtheuniton,pressandholdDISPuntiltheclockbegins
toflash,thenrelease.PressTUNE
nn
toadjustthe
hoursandTUNE
ll
toadjusttheminutes.PressDISP
momentarilytosavetheselectedtime.
Theclockwilldisplay12-hourAM/PMtimeinUSAfrequency
spacingmode(PM10
:
00).InEuropeanfrequencyspacing
mode,theclockwilldisplay24-hourtime(22:00).
Note:24-hourtimeandEuropeanfrequencyspacingarenot
availableiftheHDM90HDRadio™tunerareconnected.
PressandholdAUDIO/MENUformorethan3secondsto
accessthesetupmenu,thenpressAUDIO/MENUtocycle
throughmenuoptions.Whendesiredoptionappearsinthe
display,rotatethevolume knobleft/righttoadjustoractivate
desiredfunction.PressESCtoexitanymenuorsubmenu.

Dual XML8150 Specifications

General

MP3 playback	Yes
CD-R playback	No
Audio formats supported	MP3, WMA
Supported radio bands	AM, FM
Preset stations quantity	30
Output power	240 W
Product color	Black
Equalizer bands quantity	3
Bluetooth profiles	A2DP, AVRCP
Line outputs (RCA)	6
Compatible memory cards	SD, SDHC
RMS rated power	72 W
Key illumination color	Blue
