4
Off: Connection to local network OK
Flashes once/second: Delivery of alarm via Ethernet failed.
Lit: Connection error to local network. Check the cable.
5
Flashes:Waiting for GPRS/3G network
Off: GPRS/3G connection OK
Lit: GPRS/3G error
2-5
Indicates signal strength on GPRS/3G link when DIP switch 4 is
set to ON. During checking all LEDs must light up for optimal
reception.
5
Flashes three times together immediately after alarm
transmission: alarm transmission not OK
6.3 Power supply and current consumption
Power supply
11-30VDC
Current consumption
Unit programmed for GPRS/3G only: Idle mode approx. 130 mA
Unit programmed for wired IP and GPRS/3G: Idle mode approx. 230 mA
6.4 Approvals
Product
EN50131-1 / EN50136-1-1
CPR EN 54-21*
DALM1000
Security Grade 2
No
DALM2000
Security Grade 3
No
DALM3000
Security Grade 4
Yes
DALM5000
Security Grade 4
Yes
*0845-CPR-232.1747, “Alarm transmission and fault warning routing equipment for fire alarm systems
installed in buildings”
Communication
path
Reporting time
Availability
Overall
GPRS/3G
T4
A4
ATS5
Fixed Internet
T6
A4
ATS6
GPRS/3G: D3, M4. NOTE: For fulfilment of requirement D4 according to EN54-21 Type 1, encryption
and certificate check must be switched off in the transmitter in cases where only GPRS/3G
is to be used.
Fixed Internet: D4, M4.
DALMx000 is developed with reference to and produced according to the ISO9001 quality system. All of
the product components are specifically selected to meet the highest standards of quality and
functionality and to operate within the respective component specification, assuming an ambient climate
in accordance with class 3k5 in EN60721-3-3: 1995.
