Connect the positive cable (10), previously assembled
to ABS cable (11), to battery positive terminal, and
negative cable (12) to battery negative terminal, by
starting the other screw (9).
Tighten the terminal screws (9) to a torque of 5 Nm
±10% and apply grease onto the battery terminals to
prevent oxidation.
Reinstall the battery (8) in the support, positioning the
cables (10) and (11) as shown in (Fig. 157).
Fig. 156
Fig. 157
205
