Clock setting function
This function sets the clock. To access the function it
is necessary to view the "setting" menu page 73, use
button (1) or (2) to select the "CLOCK" function and
press the reset button (4) to confirm.
In the following screen the message "SETTING" is
highlighted in green (A); now, press the reset button
(4) for 3 seconds to edit the time displayed on the
instrument panel on handlebar, and the "SETTING"
indication highlighting becomes grey (B).
Clock setting
On entering this mode, the message "AM" will flash;
if you press button (2) the message "PM" flashes;
press button (2) again to go back to the previous step
(if it is 00:00, when switching from AM to PM, 12:00
will be displayed); press button (1) to access hour
setting mode, the hours start flashing; each time you
press button (2), the digit will increase by one hour.
If button (2) is kept pressed, the number increases
cyclically in steps of one hour every second (when the
button is held depressed, the hours do not flash).
Pressing button (1) gives access to the minute setting
mode; minutes start to flash. Each time you press the
button (2), the digit will increase by 1 minute. If you
hold the button (2) down , the count increases
cyclically in steps of 1 minute every second.
If the button (2) is held depressed for over 5 seconds,
minutes will increase by 1 minute every 100 m (while
the button (2) is held depressed, the seconds will not
flash).
If you press button (1) setting is completed and the
instrument panel on tank display "SETTING" item is
again highlighted in green (C).
To exit, select "EXIT" and press the reset button (4).
Note
In case of battery off, when the Voltage is
restored and upon next Key-On, clock will have to be
set again (it will automatically start counting from
00:00).
105

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ducati Diavel and is the answer not in the manual?

Ducati Diavel Specifications

General IconGeneral
Displacement1, 262 cc
Torque129 Nm (95 lb-ft) @ 7, 500 rpm
Transmission6-speed
Dry Weight223 kg (492 lb)
Seat Height780 mm (30.7 in)
Engine TypeL-Twin, 4 valves per cylinder
FrameTubular steel trellis
Rear SuspensionMonoshock, adjustable for preload and rebound damping
Front BrakeDual 320 mm discs, Brembo M4.32 monobloc calipers, ABS
Rear Brake265 mm disc, Brembo 2-piston calliper, ABS
Fuel Tank Capacity17 L (4.5 gal)
Safety EquipmentABS, Ducati Traction Control (DTC), Riding Modes
