Ducati Diavel - Passenger grabhandle

Passenger grabhandle
Passenger grab handle (1, Fig. 117) is located inside
the tail guard; to take it out, remove the seat (see
"Removing the seat" on page page 161), pull knob
(2, Fig. 117) while taking out the grab handle
(1, Fig. 117) from its housing until it is fully extended.
Warning
Before use, pull grab handle back and forth to
ensure that it is locked in the correct position.
To put it back, pull knob (2, Fig. 117), push grab handle
(1, Fig. 117) in its housing until it is completely flush
with the tail guard (1, Fig. 118) and refit the seat (see
"Refitting the seat" on page page 161).
1
2
Fig. 117
1
Fig. 118
166
