Ducati Diavel - Main components and devices; Position on the vehicle

Main components and
devices
Position on the vehicle
1) Tank filler plug.
2) Seat lock.
3) Side stand.
4) Rear-view mirrors.
5) Front fork adjusters.
6) Rear shock absorber adjusters.
7) Catalytic converter.
8) Exhaust silencer.
4
4 7 8
1 2
36
6
5
5
Fig. 109
