Ducati Diavel User Manual

Tank filler plug
Note
To open or close the tank filler plug using the
active key, set the metal part in the middle position.
Opening
Lift the cover (1) and insert the active or passive key
into the lock.
Turn the key clockwise 1/4 turn to unlock.
Lift the plug (2).
Closing
Close the cap (2) with the key inserted and press it
into its seat.
Remove the key and replace the lock cover (1).
1
Fig. 110
2
Fig. 111
159

Ducati Diavel Specifications

General

Displacement	1, 262 cc
Torque	129 Nm (95 lb-ft) @ 7, 500 rpm
Transmission	6-speed
Dry Weight	223 kg (492 lb)
Seat Height	780 mm (30.7 in)
Engine Type	L-Twin, 4 valves per cylinder
Frame	Tubular steel trellis
Rear Suspension	Monoshock, adjustable for preload and rebound damping
Front Brake	Dual 320 mm discs, Brembo M4.32 monobloc calipers, ABS
Rear Brake	265 mm disc, Brembo 2-piston calliper, ABS
Fuel Tank Capacity	17 L (4.5 gal)
Safety Equipment	ABS, Ducati Traction Control (DTC), Riding Modes
