Ducati Diavel - Lubricate cables and joints

Lubricate cables and joints
Check the outer sheath of the throttle control cables
for damage at regular intervals. The outer plastic
cover should not be flattened or cracked.
Operate the controls to make sure the inner cables
slide smoothly inside the outer sheath: if you feel any
friction or catching, have the cable replaced by a
Ducati Dealer or Authorised Service Centre.
To avoid this kind of problem with the throttle cable,
unscrew the two retaining screws (1) to open the
case and then the grease cable ends and pulley (2)
with SHELL Advance Grease or Retinax LX2 grease.
Warning
Carefully close the control after engaging the
cable in the pulley.
Refit the housing and tighten the screws (1) to 10
Nm.
1
Fig. 142
2
Fig. 143
192
