Ducati Diavel - Refitting the seat

Refitting the seat
Make sure all parts are correctly laid out and secured
in the underseat compartment. Insert the mounts (4)
of the seat base in the projecting parts (5) of the
frame, then push the rear end of the seat until you
hear the bolt in the lock click into place.
Make sure the seat is safely secured to the frame and
remove the key from the lock.
5
4
Fig. 115
163
