Engine rpm indication
Engine revs per minute are displayed using a rev
counter featuring a grey wake needle (A).
During the first 1000 km (600 mi) of the odometer
(vehicle running-in period), or up to the first service,
a engine rpm limiter is set and is indicated
when the needle wake becomes amber yellow.
the running-in period or the first
inspection, the limiter indicates and advises
the rider to ride at lower revs when the engine is cold.
The limiter threshold changes according to
the engine temperature:
- if the engine temperature is below 50 °C
(122 °F), the rpm threshold is 8,000 rpm;
- if the engine temperature is within 50 °C (122 °F)
and 60 °C (140 °F), the rpm threshold is 9,000
rpm;
- if the engine temperature is above 60 °C
(140 °F), the rpm threshold is 10,000 rpm.
When the needle wake becomes amber yellow and
blinking, the instrument panel is warning the
rider to up.
The wake becomes flashing red when the rev limiter
trips (Over-rev): in this case the rev limiter light
(01, Fig 71) turns on, too.
If the number of rpm is lower than 1000 rpm, the
needle wake is not displayed.
Air
24
°C
100
km/h
90
°C
10:34
pm
rpm X1000
4
1
2
3
5
6
7
8
10
12
44
Gear
Total
Range
2017 km
250 km
Phone
Music
Setting menu
URBAN
A
Fig 77
