Side stand
Place the motorcycle on the side stand only
when you are not going to use it for periods of
time. Before lowering the side stand, make sure that
the bearing is hard and flat.
Do not park on or pebbled ground or on asphalt
melted by the sun, etc. or else the motorcycle may
fall over. When parking downhill, always position the
motorcycle with the rear wheel facing downhill.
To pull down the side stand, hold the motorcycle
handlebar with both hands and push down on the
side stand (1) with your foot until it is fully extended.
Tilt the motorcycle until the side stand is resting on
the ground.
To move the side stand to its rest position (horizontal
position), lean the motorcycle to the right while
the thrust arm (1) with your foot.
To ensure trouble-free operation of the side stand
joint, thoroughly clean it and then use SHELL
Alvania R3 grease to lubricate all friction points.
Do not sit on the motorcycle when it is
on the side stand.
Note
Check for proper operation of the stand
mechanism (two springs, one into the other) and the
safety sensor (2) at regular intervals.
Note
It is possible to the engine with stand
unfolded and gearbox in neutral.
Fig 20
37
