Restoring motorcycle operation via
the PIN Code
In case of key acknowledgement system or key
malfunction, the instrument panel allows the user to
enter his/her own PIN code to temporarily restore
motorcycle operation.
If the PIN code has been activated via the "PIN Code"
function in the menu page 161, the
instrument panel displays "PIN Code" and next to it
the spaces for the four digits of the PIN to be
entered.
Entering the code:
●
The 2 arrows above and below the digit indicate
that the number can be changed from 0 to 9
using (1) and (2).
●
Press ENTER (3) to confirm and move on to the
following digit.
●
Repeat the procedure until entering all 4 digits.
Once the digit is set, press ENTER and the
instrument panel behaviour will be as follows:
●
if there is a problem during the PIN check, the
instrument panel displays an error for 2 seconds
and then passes to the main screen;
Fig 61
Fig 62
76
