Power outlet
The motorcycle is equipped with two 12V power
outlets protected by a fuse (socket, 7.5A) located in
the front fuse box.
This fuse protects against any line overloads:
- front power socket;
- rear power socket;
The maximum current that can be drawn from the
power outlets (meant as the current on socket (1) +
current on socket (2) is equal to 7.5A.
Connecting higher loads will blow the line fuse and it
will be necessary to replace it with a new one having
the same rating.
When the engine is do not leave
accessories connected to the power outlets for a
long period of time as the motorcycle could
run flat.
The power outlets are located at the front RH side (1)
on instrument panel and at the rear end, under the
passenger seat (2).
Fig 18
Fig 19
36
