Go to a dark place or to a low light environment.
Switch low beam on and cover the right low beam.
Adjust the uncovered low beam by
working the adjusting screw (1).
To reach the screw (1) more easily, we recommend
turning the steering all the way to the right.
Turn the screw (1) with a Phillips screwdriver.
Turn screw (1) clockwise to move headlight down (D),
or counter-clockwise to move beam up (U).
Once the low beam has been adjusted, cover it
and carry out the same procedure using the screw (2)
to adjust the right low beam.
To reach the screw (2) more easily, we recommend
turning the steering all the way to the
Turn screw (2) clockwise to move headlight down (D),
or counter-clockwise to move beam up (U).
Switch high beam on.
Have the light beam adjusted at a Ducati
Dealer or Authorised Service Centre.
The headlight lens might fog up if the vehicle is used
under the rain or washing. Switch headlight on
for a time to dry up any condensate.
Fig 230
Fig 231
226
