Owner's Manual for DUKE TSC Proofer Oven
with Touch Screen Controls
14
SPECIAL FUNCTIONS – PIN Number Entry
CLEAR
ENTER
PIN CODE
EXIT
****
OK
CENTIGRADE MODE
Now Disabled
Figure 8: Centigrade Mode Disable Screen
CHANGE TEMPERATURE UNITS (F ˚ to C ˚)
1. Press and hold the OVEN button for Approx
5 seconds or until the Special Functions
Screen opens.
2. Press CLEAR, 2 5 8 0 and ENTER.
3. Press OK. CENTIGRADE MODE is now
enabled.
SPECIAL FUNCTIONS – PIN Number Entry
CLEAR
ENTER
PIN CODE
1 2
3
4 5
6
7 8
9
0
EXIT
SPECIAL FUNCTIONS – PIN Number Entry
CLEAR
ENTER
PIN CODE
EXIT
****
OK
CENTIGRADE MODE
Now Enabled
Figure 7: Centigrade Mode Enable Screen
Figure 6: Special Functions Screen
1. Press and hold the OVEN button for Approx 5
seconds or until the Special Functions Screen
opens.
2. Press CLEAR, 2 5 8 0 and ENTER.
3. Press OK. CENTIGRADE MODE is now
disabled. This returns the unit to Fahrenheit
mode.
