Printed in Germany / M-MT-BOS
• Edition 11.99 • # 231 763
100 … 112
Parameterisation mode can be accessed only from the operating-mode display
when the controller is on standby ("OFF"). Parameterisation mode is used to
view important operating parameters and adjust the settings by means of the
buttons on the touch-sensitive display.
Paramterization mode defines access priority in such a way that all service-
level parameters can be configured with MPA Vision.
This display mode is exited after a 20-second timeout or if the readout is
scrolled past the last display image.
Display in parameteriza-
tion mode
Gas firing, electronic
modulation
Gas firing, pneumatic
modulation
Oil firing, three stage
■ The parameterisation-mode dis-
play can be accessed only from
the operating-mode display in
standby status.
