Printed in Germany / M-MT-BOS

• Edition 11.99 • # 231 763

56 … 112

Press "1" and "2" simultaneously to exit

the setup mode.

Generate CRC check-

sum from settings.

Set flag to "programmed"

End of setup mode

Gas firing pneumatic

modulation

Setup mode

Gas firing, pneumatic

modulation
