Dungs MPA22 User Manual

Printed in Germany / M-MT-BOS
• Edition11.99 • # 231 763
51 … 112
Setup mode
Gas firing, electronic
modulation
Timeout
approx. 30 min.
Restart
Servo drive, gas
1
+
1
–
Servo drive, air
2
+
2
–
20
19
1
2
P
S
G
L/A
h
l,m
3
i
P
S
G
L/A
h
l,m
3
i
1
2
P
S
G
L/A
h
l,m
3
i
1
2
End of setup mode
Gas firing, modulated
Generate CRC check-
sum from settings.
Set flag to
"programmed"
21
2
–
Servo drive, air
2
+
2
–
Servo drive, air
2
+
Set characteristic point P9
max. P8 +25.5
°
and P9 ≤ 90.0
°
min. P8
Set minimum burner load
Pmin.
Range = P1 to bo
The air-flow control flap is the refer-
ence variable
Set maximum burner load
Pmax.
Range = bu to P9
The air-flow control flap is the refer-
ence variable
Set minimum burner load
max. bo
min. P1
Set maximum burner
load max. P9
min. bu
Press "1" and "2" simultaneously to
exit the setup mode.
