Breaking capacities
Total max. 10 A
Designation Breaking capacity
Burner motor 230 VAC/4 A/cos ϕ = 1
Burner motor (endurance run) 230 VAC/4 A/cos ϕ = 1
Ignition transformer 230 VAC/3 A/cos ϕ = 1
Valve Y1 + status display 230 VAC/2 A/cos ϕ = 1
Valve Y2 230 VAC/2 A/cos ϕ = 1
Valve Y3 230 VAC/2 A/cos ϕ = 1
Fault output 230 VAC/1 A/cos ϕ = 1
Safety sequence (pressure switch max. gas)
230 VAC/10 A
Pulse generator 24 VDC/2 mA
Pressure switch air stage 24 VDC/20 mA
Pressure switch min. gas 24 VDC/20 mA
Pressure switch VPS 24 VDC/20 mA
Flame detector
Ionisation electrode 230 VAC
UV diode 230 VAC
Photoresistor 5 VDC
Servomotor gas 24 VDC/max.150 mA
Servomotor air 24 VDC/max.150 mA
Display board 24 VDC/max.10 mA
Bus interface 5 VDC/10 mA
Temperature or pressure regulator 230 VAC/10 mA
Negative capacity or stage 2 230 VAC/10 mA
Positive capacity or stage 3 230 VAC/10 mA
Specifications
Flame supervision
Servomotors
Display module
Minimum display
Coding plug / oil
Coding plug / gas
Fault unlock
Pulse counter input
Communication
As-delivered state
Installation position
Dimensions
Mounting bracket
Ionisation, UV diode, with additional photoresistor for oil burner
Stepped-motor servomotor with integrated stepped motor driver and digital
acknowledgement via encoder disk
SAD 0.6 with 0.6 Nm torque
SAD 1.2 with 1.2 Nm torque
Display module AM01 with 71/2-digit LCD display and 5 operating keys incl.
unlocking key. Connected via a 6-pole cable, cable length: max. 1 m
Unlocking key with fault indicator lamp instead of display unit
Coding plug CS01 for operation as oil burner instead of the servomotor gas
Coding plug CS02 for operation as gas burner in combination with pneumatic
system instead of the servomotor gas
By means of unlocking key
Connection possibility for a floating pulse counter contact for fuel volume ac-
quisition, adjustable divisor in EEPROM.
Connection to the eBUS via an approved MPA/eBUS interface or to a PC via an
approved MPA/PC interface.
The interfaces must be electrically isolated (4 KV/8 mm) as per VDE 0551.
The automatic burner control system has a default state so that a basic setting
is available for the burner manufacturer or in case of replacement.
Arbitrary
200 mm x 105 mm x 60 mm
For upright assembly of the automatic burner control system
