Printed in Germany / M-MT-BOS
• Edition 11.99 • # 231 763
6 … 112
Setpoints for the servomotor char-
acteristics
Setpoints for gas firing, pneumatic
modulation
Setpoints for gas firing, electronic
modulation
Setpoints for oil firing, three stage
The following setpoints for the air motor and gas motor in each operating mode
may only be changed in setup mode; they are not enabled until the settings for
automatic burner operation have been completed.
The setting values are to be recorded in the setup log after the burner has been
set and should be kept in a safe place on the machine and in a suitable form.
Setting range on standby
Setting range on standby
Air motor P9 0.0°…90.0°
Air motor P1 0.0°…P9
Air motor P0 0.0°…90.0°
Setting range in operation
Air motor P9 P1…90.0°
Air motor P1 0.0°…P9
Air motor P0 0.0°…90.0°
Setting range on standby
Air and gas motor P9 0.0°…90.0°
Air and gas motor P1 0.0°…P9
Air and gas motor P0 P1 - 25.5°…P1 + 25.5° and P0 ≥ 0.0°
Setting range in operation
Air and gas motor P0 P1 - 25.5°…P1 + 25.5° and P0 ≥ 0.0°
Air and gas motor P1 0.0°…P2
Air and gas motor P2 P1…P3
Air and gas motor P3 P2…P4
Air and gas motor P4 P3…P5
Air and gas motor P5 P4…P6
Air and gas motor P6 P5…P7
Air and gas motor P7 P6…P8
Air and gas motor P8 P7…P9
Air and gas motor P9 P8…90.0°
Lower limit bu 0…bo (0 = P1; 200 = P9)
Upper limit bo bu…200 (0 = P1; 200 = P9)
Setting range on standby
Air motor P9 0.0°…90.0°
Air motor P3 0.0°…P9-0.1°
Air motor P1 0.0°…P3-0.1°
Air motor P0 0.0°…P1
Air motor P2 P1 + 0.1°…P3
Air motor P4 P3 + 0.1°…P9
Setting range in operation
Air motor P0 0.0°…P1
Air motor P1 0.0°…P2 -0.1°
Air motor P2 P1 + 0.1°…P3
Air motor P3 P2…P4 -0.1°
Air motor P4 P3 +0.1°…P9
Air motor P9 P4…90.0°
