Dungs MPA22 User Manual

Printed in Germany / M-MT-BOS
• Edition11.99 • # 231 763
61 … 112
Prompt for burner start
Contact GWmax. closed to start
the burner: temperature con-
troller must be closed.
If start is successful, the burner
remains in the ignition position.
If flame does not stabilize, repeat
the procedure with new ignition
point P0.
When burner is lit:
1.Set oil-pressure regulator to
desired value.
2.Precision-adjust ignition point.
max. P1
min. 00.0°
Press "+" to leave ignition setting
–
+
3
GWmax
"ON"
Burner start
position
Startup see start
phase
"Oil firing, three-stage"
"P" also lights up
Burner fired in
ignition position
RESTART
Timeout
approx. 30 min.
4
P
S
i
G
L/A
h
l,m
3
P
S
i
G
L/A
h
l,m
3
5
6
Servo drive, air
2
+
2
–
Setup mode
Oil firing, three stage
