F.19
DUPLEX 340/420/620
1.0
113
2
3
3
4
1
To clean the appliance, proceed as follows:
1) Disconnect the power cord plug from the socket.
2) Remove the cover 1.
3) Remove the recovery tank 2.
4) Remove the tanks 3.
5) Wash the tanks and the recovery tank and dry them.
CAUTION
Apart from the tank that encloses the steam generator (Steam /
Steam Plus models), the tanks can be washed under running water.
Pay particular attention to dirt and / or foreign objects that could
clog the valves (7) inside the tanks.
6) Remove the brushes 4 and clean them (see section “7.2.2 Cleaning the brushes”).
7) Clean the rest of the appliance thoroughly using a wet sponge and then dry it.
8) Remove any residues of dirt from all the appliance using a brush.
9) Once dry, replace all the components that were previously removed.
Rev.
MAINTENANCE
EN
