4.2 DESCRIPTION OF THE COMPONENTS
1 Motor Protector 11 Mop Up / Down
2 Handle 12 Transport wheels
3 Detergent lever 13 Steam generator
4 Handle 14 Pump switch
5 Power cord 15 Motor
6 ABS detergent tank 16 Steam generator switch
7 Brush pressure regulator 17 Main switch
8 Cover 18 Safety handle (Start & Stop)
9 Recovery tank 19 ABS water tank with filter
10 Brushes 20
STAINLESS STEEL water tank with
filter
