20
Preparation Before Use
REFERENCE
Disconnect the connector in the module.
Grasp the handles to take out the module by lifting it
up.
Install the module according to the
positioning pin
of
slot 2
.
Tighten the
fi xing screws
(two each) to secure the
module.
Close the
top cover
.
When using the creaser module, pull out the
creaser tool.
(→ P.31 Creaser Module)
