22
Slitter Modules
Knob
Thumb screw
Thumb screw
Pin
Pin
Gutter defl ector
Slitter unit (left) Slitter unit (right) Slitter unit (left) Slitter unit (right)
● Slitter units (left/right)
• Document feed side
• Document ejection side
● Margin slitter units (left/right)
• Document feed side
• Document ejection side
Margin guide (left)
Margin guide (right)
Knob
Thumb screw
Thumb screw
Pin
Pin
Gutter defl ector
Margin slitter unit (left) Margin slitter unit (left)Margin slitter unit (right) Margin slitter unit (right)
