Duplo DocuCutter CC-229 Service And Parts Manual

- 23 -
Explosive View and WEEE (Fig.1)
NO P/N Name Q’TY
1 883-010-000A
Asm, Side Plate, Non-Operating 1
2
883-020-000A
Asm, Side Plate, Operating
1
3 883-030-000A
Asm, Electric Panel 1
4 883-040-000A
Cover, Front Safety 1
5 883-050-000A
Asm, Feed Table 1
6 881-G00-000A
Bar, Tie 2
7 883-070-000A
Asm, Feed Ramp 1
8 881-N00-000A
Asm, Feed Roller 1
9 881-N10-000A
Asm, Transport Roller, Lowe, Front 1
10
881-N20-000A
Asm, Transport Roller, Lower, Middle 1
11
881-N30-000A
Asm, Transport Roller, Lower, Rear 1
12 881-L00-000A
Asm, Transport Roller, Upper, Front 1
13 881-M00-000A
Asm, Transport Roller, Upper, Rear 1
14 883-140-000A
Asm, Die Skew Adjustment 1
15 883-112-010A
Asm, Dummy Module 1
883-150-000A
Asm, Die Module
Option
16 881-Q00-000A
Asm, Upper Knife Driving 1
17 881-P00-000A
Asm, Lower Knife 1
18 883-180-000A
Asm, Slitter Mounting Chassis 1
19
883-190-000A
Asm, Slitter Alignment 1
20
881-112-0000
Module, Slitter, 2X3.5” 1
21 883-210-000A
Asm, Top, Safety Cover 1
22 883-220-000A
Asm, Cover, Rear 1
23 883-230-000A
Cover, Rear Lower Safety 1
24 00M-000-0003
Magnets 50 * 50 * 12T 1
25 883-250-000A
Asm, Waste Bin 1
Fig. 1
