Duplo DocuCutter CC-229 Service And Parts Manual

- 33 -
883-070-000A Feed Ramp Asm
NO P/N Name Q’TY
1 881-116-000A
Ramp, Feed 1
881-F01-010A
Plate, Ramp, Feed 1
881-F01-020A
Paper Registration 4
2 00B-000-0905
Angle Bracket 4
3 881-F03-000A
Asm, Separator 1
881-F03-010A
Base, Separator Asm 1
881-F03-020A
Lower Limit Plate, Separator 1
881-F03-030A
Pin, Separator Compression Spring Holding 1
881-F03-040A
Shaft, Pivot, Separator Holding Plate 1
881-F03-050A
Holder, Separator 1
881-F03-060A
Shaft, Pivot, Separator Holder 1
00E-M04-000E
E-Ring M4 2
4
00S-000-1604
Separator, CC-228
1
SEPERATOR MTG 1
POM
SEPERATOR PAD 1
PU
5 881-225-000A
Guide, Feed Ramp
1
6 883-070-060A
Asm, Paper Sensor 1
00S-00E-ESB5
Sensor, EE-SB5 1
00W-883-2463
Wire, 63cm, 24 AWG 1
2PH-716-102F
Housing, Female, 2-pin 1
7
00S-881-0003
Spacer, TXP PLATE 3MM 2
