Duplo DocuCutter CC-229 Service And Parts Manual

- 42 -
883-150-000A Die Module (Fig. 14)
NO P/N Name Q’TY
1 883-150-010A
Bracket, Die Module 1
2 883-150-020A
Sie Plate, Die Module 2
3 881-R17-000A
Handle 2
4 883-150-040A
Thumb Screw 2
5 00E-M04-000E
E-Ring M4 5
6 883-150-060A
Bracket, Lower Die Base Mounting 1
7
883-150-070A
Base, Lower Die 1
8
00M-000-0002
Magnet, Rear Cover Position 10
9
883-150-090A
Pin, ψ4*6, Die Plate Positioning
4
10 00B-0LM-06UU
Linear Bearing, LM-06-UU 4
11 883-150-110A
Bar, Upper Die Base Mounting 1
12 883-150-120A
Base, Upper, Die Module 1
13 883-150-130A
Pin, Die Module Sliding 4
14
883-150-140A
Plate, Cam Contact 2
15
883-150-150A
Bracket, Spring Holding 2
16
883-150-160A
Spring,
2
17 883-150-170A
Shaft, Die Module Driving 1
18 883-150-180A
Cam 2
19 00B-000-6005
Ball Bearing, 6005ZZ 2
20 00C-000-4025
Collar, OD 40, ID 25 2
21 00B-00F-6901
Ball Bearing, LF-6901ZZ 2
22 00G-M10-3112
Gear, M1.0, 31T, ID 12 1
23 883-150-230A
Triger 2
24
883-150-240A
Guide Plate 1
25
883-150-250A
Die Plate, Crease, Lower 1
26
883-150-260A
Die Plate, Crease, Upper
1
Fig. 14
