Duplo DocuCutter CC-229 Service And Parts Manual

- 28 -
00B-000-0943
Bracket, Interlock Switch Mounting 1
00S-000-6105
Switch, Interlock, 1
00W-883-2233
Wire, 33cm, 22AWG 1
2PH-716-102F
Housing, Female, 2-pin 1
883-020-232A
Asm, Interlock Switch, Rear Cover 1
00B-000-0943
Bracket, Interlock Switch Mounting 1
00S-000-6105
Switch, Interlock 1
00W-883-2257
Wire, 57cm, 22AWG 1
2PH-716-102F
Housing, Female, 2-pin 1
883-020-233A
Asm, Interlock Switch, Waste Bin 1
00B-000-0943
Bracket, Interlock Switch Mounting 1
00S-000-6105
Switch, Interlock, 1
00W-883-2267
Wire, 67cm, 22 AWG 1
2PH-716-102F
Housing, Female, 2-pin 1
24 00C-000-2050
Cover, Interlock Switch 2
25
883-020-250A
Asm, PCB, Control Panel 1
PCBA
26 00D-000-0304
Display, LCD, 4 Row x 20 1
PC/PCBA
27 883-020-270A
Key Pad, CC-229 1
28 883-020-280A
Case, L, CC-229 1
29 00B-0NB-2430
Bushing, Cable Guard, ID24 OD30 3
Fig. 3
