DocuCutter 545
Note: If the slitters do not move to their indicated positions
within approximately 5 seconds, “E5 - SLITTER ERROR”
will be displayed.
9. When the CCD scans the Bar Code, the document
feeding stops, and each slitter returns to its home
position.
Note: If the slitters do not return to their home positions
(all slitter sensors aren’t blocked) within approximately 5
seconds, “E5 - SLITTER ERROR” will be displayed.
10. After the slitters return to their home positions, the
slitters move to their indicated positions according
to the preset job data detected by scanning the Bar
Code.
Note: If the slitters do not move to their indicated
positions within approximately 5 seconds, “E5 -
SLITTER ERROR” will be displayed.
11. After the slitters are positioned properly, the
document is fed until the CCD detects the vertical
line of the REG Mark.
Note: If the CCD cannot scan the vertical line within 10
mm of feeding, “E4 - REG MARK ERROR will be
displayed.
12. Each slitter is adjusted for any registration error.
13. The document is fed backwards until PPS2 detects
its leading edge.
14. The document is fed by 0.1mm increments until the
CCD detects the horizontal line of the REG Mark.
© 2002, Duplo USA Corporation DocuCutter 545 Training Guide 37
