DocuCutter 545
PWB Locations
The locations of each of the Printed Wiring Boards
(PWBs) in the DocuCutter DC-545 are shown in Figure
10.
Power
PWB
Main
PWB
Memory
PWB
Switching
Power Supply
PWB
Panel
PWB
Figure 10. PWB Locations
© 2002, Duplo USA Corporation DocuCutter 545 Training Guide 19
