DocuCutter DC-545 Maintenance Procedures
The following Maintenance procedures are available in the
DocuCutter DC-545 Field Service Manual. They are
presented here for information only.
;Q W  YKNN WUG VJ G IWK FGNK PGU UJ QYP K P 6C DNG  VQ  RGTHQTO 
OC K PVGPC PEG VY K EG  C  [GC T QP VJ G &Q EW %W VVGT &% 
 DC UGF QP PQ OQTG VJ C P GK IJ V J QWTU WUG C  FC [ J GC XK GT
WUG YKNN TGSWK TG OQTG H TGSWGPV OC K PVGPC PEG 
ITEM ACTION
PPS1 (Paper Path Sensor 1) Use a brush to clean any paper dust, etc. from the
upper and lower sensor portions.
PPS2 (Paper Path Sensor 2) Use a brush to clean any paper dust, etc. from the
upper and lower sensor portions.
PPS3 (Paper Path Sensor 3) Use a brush to clean any paper dust, etc. from the
upper and lower sensor portions.
PPS4 (Paper Path Sensor 4) Use a brush to clean any paper dust, etc. from the
upper and lower sensor portions.
PAPER LEVEL SENSOR Use a brush to clean any paper dust, etc. from the
sensor.
ROLLERS Use a lint free cloth moistened with water to clean the
Rollers.
ROLLER BEARINGS Clean and oil the Roller Bearings.
SUCTION BELTS Clean the Belts with rubber belt cleaner.
SLITTERS Clean and oil the Slitters.
CUTTER Clean and oil the Cutter Assembly.
Table 1. Recommended Maintenance Schedule
