DocuCutter 545
AF-100 OPERATOR CONTROLS
1. Level adjustment lever for adjusting the level of the
paper stack
2. Separator adjustment knob for adjusting the
amount of space between the mechanical paper
separators and the top sheet of paper
3. Airflow adjustment knob for adjusting the amount of
airflow used to separate the sheets in the paper
stack
4. Skew adjustment knob for adjusting the skew of the
paper stack
5. Stoppers for holding the rear edge of the paper
stack
© 2002, Duplo USA Corporation DocuCutter 545 Training Guide 17
