144
T
ouch "ON".
Set the time.
T
ouching “+” increments the value.
T
ouching “-” decrements the value.
Y
ou can set time from 1 to 99 minutes.
The value can be also entered using the NUMERIC
keys.
T
ouch "OK".
"AUTOMA
TIC RESET" is set.
T
ouch "END".
Setting Function:
Automatic Reset
161
163
