166
● Use a roll master designed only for use in this machine.
● Do not put anything heavy on the roll master box. Master may be scratched and it causes
the machine not to perform master making normally.
● Do not leave the roll master taken out from the roll master box as it is. Foreign materials
may attach to the surface of the master and cause the machine not to perform master
making normally.
● Do not store a roll master in a place subject to direct sunlight, high/low temperature, and
high/low humidity.
The message “NO MASTER” is displayed on the touch panel LCD when the roll master is used
up. Replace the roll master according to the following procedures.
Replacing Roll Master
Replacing Roll Master
How to Replace Roll Master
Press the “scanner button” to slide the scanner unit.
Press the “master cover open lever”.
The master cover will open up.
Do not touch the heat generator of the thermal
head.
Doing so may cause damages, leading to a
malfunction of master making.
Lift out the used roll master .
● Do not remove the cover affi xed with
Warning Label.
● Personnel may be injured by the movable
cutter inside the machine.
CAUTION
Thermal head heat generator
IMPORTANT
IMPORTANT
V3M0510
V3M0511
V3M0511
To Next Page
