16 Appendix II: D−LX 200 InformationCentre PC-Version
144 D−LX 200, D−LX 720
Figure 16.6: System Settings
Threshold Intensity
(1st value). View of the setting of the Intens. rotary switch.
Switch / Value
(2
nd
value). Intensity threshold
Threshold Frequency
(1st value) View of the setting of the Freq. rotary switch..
Switch / Value
(2
nd
value) frequency threshold
Gain Characteristic
View of the gain characteristic curve
Firmware
Fimware Version/Revision of the D-LX 200
Connection Setting
View of the interface used and
of the used modbus slave address
Analogue Output
Setting
Analogue output 0..20mA 4..20mA
Paths
Storage path + file name of the archive file were the
measured data is recorded
Data Count
Number of records held in the archive file
Safety Time
Safety time display
SerialNo
Serial number
Dev.Name
Device type (D−LX 200, D−LX 720)
Table 16.1: System Settings
