DURKOPP ADLER 867 Additional Instructions

Assembling the remaining thread monitor
Additional Instructions 867/867-M PREMIUM - 00.0 - 07/2018 15
Efka control (class 867 only)
Recommended mode for remaining thread monitor function:
Parameter F-195 on value "3"
Information
A detailed functional description of the remaining thread monitor functions
and the stitch counts can be found in the instructions for use of the DA82GA
or DA321G controls.
Parameter Value Function
F-195 0 Remaining thread monitor off
F-195 1 No stop after 1st detection Bobbin empty,
after thread cutting, sewing foot down
F-195 2 With stop after 1st detection Bobbin empty,
after thread cutting, sewing foot up
F-195 3 With stop after 1st detection Bobbin empty,
after thread cutting, sewing foot down
F-195 4 Hook thread monitoring via preset number
of stitches
Light barrier remaining thread monitor control
without function
F-195 1 - 3
085 0 - 9990 Number of stitches for remaining thread
Count from 1st detection Bobbin empty
until stop
F-195 4
085 0 - 9990 Number of stitches A for hook thread
monitoring
Pre-set number of stitches is counted
downwards to "0". When the value "0" is
reached: Stop at value 0 and after thread
cutting sewing foot down.
086 0 - 9990 Number of stitches B for hook thread
monitoring
Pre-set number of stitches is counted
downwards to "0". When the value "0" is
reached: Stop at value 0 and after thread
cutting sewing foot down.
086 0 - 9990 Number of stitches C for hook thread
monitoring
Pre-set number of stitches is counted
downwards to "0". When the value "0" is
reached: Stop at value 0 and after thread
cutting sewing foot down.

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
