Assembling the remaining thread monitor
14 Additional Instructions 867/867-M PREMIUM - 00.0 - 07/2018
2.4 Software settings
2.4.1 Parameter settings for classes 867 and 867-M
DAC classic control
Parameter Value Function
Operator level
o 06 00 4 Remaining thread monitor
o 06 05 0 - 9999 Number of stitches for the remaining thread
monitor
o 06 06 0 - 1 Stop sewing motor when the counter
reaches 0
0 = No
1 = Yes
o 06 07 0 - 1 Sewing foot stays down after thread cutting
0 = No
1 = Yes
Technician level
t 06 00 0 - 2 Activation of the remaining thread monitor
0 = Off
1 = Right
2 = Left & right
t 06 01 0 - 1 Remaining thread monitor mode
0 = Dynamic
1=Static
t 06 02 0.0 - 3.300 V Threshold right
t 06 03 0.0 - 3.300 V Intensity right
t 06 04 0.0 - 3.300 V Threshold left
t 06 06 0.0 - 3.300 V Intensity left
t 06 06 0 - 1 Confirmation required after warnings
0 = No
1 = Yes
