The below table contains technical specifications for the 9540 IP camera:
Sensor/Lens Imaging device 0.33 inch (0.84 cm) digital sensor
Dynamic range 95 dB typical; 120 dB maximum
Sensor resolution 742 (H) x 554 (V)
Scanning system Progressive 525 NTSC lines (625 in PAL)
Synchronization Internal
Iris control automatic or manual
Auto iris lens type DC-drive
Sensitivity 0.8 lux, F1.2, 40 IRE
Signal-to-noise ratio 52 dB
Video Compression MPEG-4-based and MPEG-4 ISO 14496-2 compliant
Frame rate Up to 30 frames or 60 fields per second in NTSC (25
frames or 50 fields in PAL), programmable (full motion)
Analog output 1 composite, 1 Vpp into 75 ohms with a female BNC
connector
Resolution Scalable from 176 x 128 to 704 x 480 NTSC pixels
(176 x 144 to 704 x 576 PAL pixels)
Standard NTSC or PAL
Bandwidth Configurable between 30 kbps and 6 Mbps
Alarm Alarm input 2 dry contacts
Alarm output 1 relay contact (48V AC/DC at 100 mA max.)
Network Interface Ethernet 10/100Base-T
Connector RJ-45 jack
Protocols Transport: RTP/IP, UDP/IP, TCP/IP, multicast IP
Others: DNS and DHCP client
Security SSL-based authentication
Power Supply voltage PoE 802.3af
Power consumption 7.0W maximum
Physical Enclosure Metal case
Weight 1.19 lb. (0.54 kg)
Environment 32°F to 113°F (0°C to 45°C)
Humidity 95% non condensing at 122°F (50°C)
Lens mount C or CS mount
Camera mount 0.25 inch (0.64 cm) UNC-20 screw, located on the
bottom of camera housing
Management Configuration Remote using Latitude NVMS, Internet Explorer 6.0,
Device Configurator, or Telnet
Certification/ Regulation USA FCC part 15 (subpart B, class A)
Canada ICES-003/NMB-003
Europe CE marked, EN 55022:1998 Class A, EN 55024
